Coatesville, Auckland
Coatesville Mansion
Project Information:
Liquid Automation performed an extensive overhaul of the property’s Audio, Video, Security, and Lighting systems.
Upgrade of AV systems, IT Networks, CCTV, Security and Lighting.
Addition of Gaming systems in the main dwelling along with an AV upgrade of the 9 bedroom Guest House.
The properties and external buildings were all converted from wireless connections to multiple single-mode fibre connections.
Control
6 x Crestron processors
Crestron 8″ wireless touch panels
18 Custom iPod Touch/iPhone touch panels
Audio Video Server
10 Kaleidescape players with three Blu-ray vaults.
Visual
83″ Samsung LCD Panels
55″ Samsung LED Panels
25 x MySky HDi Satellite Decoders
Crestron Digital Media Matrix
Audio
B&W 800 series loud speakers with DB1 subs
Stealth acoustic LR3 invisible in-ceiling loud speakers thoroughout
Atlantic Technology subwoofers
Class-A amplifiers
Labgruppen power amps
BiAMP – audio distribution
SpeakerCraft OE8 outdoor loud speakers
Gate PA system over fibre
Security
Two master monitoring stations with multiple high definition IP cameras
Automation
Curtain control
Blind control
Lighting control
Heating control
Access control
Gate control
Features
Custom iPhone control has the ability to control all aspects of the house; heaters, curtains, lighting, doors, audio visual systems along with the ability to view live video feeds from all the cameras directly on the iPhone inside our application.
Do not disturb button from the iPhone app for the Master’s wing locks all access to the area so that staff know not to come in.
Multiple WAN links to the house with automatic failover for internet – If the fibre connection stops working, this would then automatically switch to the dedicated wireless link to the sky tower, and if this failed then it would drop down to the DSL links.
Remote monitoring so if a fault happens, the system would automatically alert Liquid Automation.
9 VLANs configured allowing for each system to have a clean path to transfer data, allowing for a robust fault free system.
Texting system alerts people to the event of an emergency with a descriptive message.
